Plug-in octal relay in basic design with power contacts, 3 changeover contacts, test button, status LED, mechanical switch position indicator, input voltage: 24 V AC
Tuotetiedot
Notes on operation
Do not connect adjacent channels to SELV/ PELV and voltages dangerous to the touch.
Notes on operation
The outputs are not suitable for switching different outer conductors.
Notes on operation
Do not use to separate SELV / PELV circuits from other circuits, because safe isolation is not guaranteed.
Product type
Single relay
Operating mode
100% operating factor
Mechanical service life
2x 107 cycles
Insulation characteristics: Air clearances and creepage distances
Insulation
Basic insulation
Overvoltage category
II
Pollution degree
2
Data management status
Date of last data management
03.05.2024
Service life electrical
see diagram
Test voltage (Winding/contact)
2.5 kVrms (50 Hz, 1 min., winding/contact)
Test voltage (Changeover contact/changeover contact)
