UM 45-PROFIL 10CM
-
Profile
1112626
Press-drawn section housings, Basic profile, profile width (internal): 41.85 mm, profile width (external): 44.8 mm, length: 100 mm, height: 44.8 mm, depth: 18.95 mm
Tuotetiedot
| Product type | Component housing lower part |
| Housing type | Press-drawn section housings |
| Housing series | UM |
| Product family | UM-Profil |
| Type | Basic profile |
| Ventilation openings present | no |
| Dimensional drawing |
|
| Height | 44.8 mm |
| Depth | 18.95 mm |
| Length | 100 mm |
| External dimensions | |
| Profile width (external) | 44.8 mm |
| Internal dimensions | |
| Profile width (internal) | 41.85 mm |
| Housing material | PVC |
| Surface characteristics | untreated |
| Ambient conditions | |
| Ambient temperature (operation) | -15 °C ... 50 °C |
