IBS SAB 24 DO 8/8
-
Distributed I/O device
2750934
INTERBUS sensor/actuator box, digital output module, 8 digital outputs, 24 V DC, 2 A, 3-conductor connection technology, IP67 degree of protection
Tuotetiedot
| Supply | |
| I/O voltage | 24 V DC 5 % (ripple) |
| I/O voltage range | 20 V DC ... 30 V DC |
| Residual ripple | ± 1.2 VPP |
| Typical current consumption | 100 mA (from the installation remote bus) |
| Digital | |
| Number of outputs | 8 |
| Output voltage | US - 1 V |
| Protective circuit | Short-circuit protection |
| Conductor cross section, rigid | 0.14 mm² ... 1.5 mm² |
| Conductor cross section, flexible | 0.14 mm² ... 1.5 mm² |
| Conductor cross section AWG | 28 ... 16 |
| Installation remote bus | |
| Connection method | SAB connector hood with MINI-COMBICON |
| Transmission physics | Copper |
| Transmission length | 188 mm |
| Dimensional drawing |
|
| Width | 61 mm |
| Height | 77 mm |
| Length | 188 mm |
| Mounting type | Panel mounting |
