PTFIX 10/S-F
-
Flange
1082917
Flange, With screw fixing, for direct mounting of the 10 mm2 FIX blocks, depth: 25.1 mm, width: 8.6 mm, height: 37 mm, color: gray
Detalhes dos produtos
| Product type | Mounting material |
| Dimensional drawing |
|
| Width | 8.6 mm |
| Height | 37 mm |
| Depth | 25.1 mm |
| Hole diameter | 5.8 mm |
| Color | gray (RAL 7042) |
| Material | PA |
| Flammability rating according to UL 94 | V0 |
| Ambient conditions | |
| Ambient temperature (operation) | -60 °C ... 105 °C (max. short-term operating temperature RTI Elec.) |
| Ambient temperature (storage/transport) | -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C) |
| Ambient temperature (assembly) | -5 °C ... 70 °C |
| Ambient temperature (actuation) | -5 °C ... 70 °C |
| Permissible humidity (storage/transport) | 30 % ... 70 % |
