Cable gland made from brass with metric thread, rotatable, IP40 protection
Product details
Product type
Protective hose screw connection
Type of the screw connection
Conduit adapter
Type
Outer thread
Cable outlet
straight
Thread type
metric
Width
37 mm
Height
36 mm
Length
36 mm
Wrench size
34 mm
Wrench size for mounting
34 mm
External dimensions
Outside diameter
27 mm
Internal dimensions
Internal diameter
20.5 mm
Color
brass color
Material
Brass, nickel-plated
Material for screw connection
Brass, nickel-plated
Components
halogen-free
Mechanical data
Type of the screw connection
Conduit adapter
Ambient conditions
Degree of protection
IP40
Ambient temperature (operation)
-40 °C ... 250 °C
Item number
3241034
Packing unit
10 pc
Minimum order quantity
10 pc
Product key
AF7DSA
Catalog page
Page 599 (C-3-2019)
GTIN
4046356711708
Weight per piece (including packing)
67.05 g
Weight per piece (excluding packing)
67.05 g
Customs tariff number
74122000
Country of origin
DE
ECLASS
ECLASS-13.0
27430310
ETIM
ETIM 9.0
EC001180
UNSPSC
UNSPSC 21.0
40141700
VDE approval of drawings
EU RoHS
Fulfills EU RoHS substance requirements
Yes
Exemption
6(c)
China RoHS
Environment friendly use period (EFUP)
EFUP-50
An article-related China RoHS declaration table can be found in the download area for the respective article under "Manufacturer declaration". For all articles with EFUP-E, no China RoHS declaration table issued and required.
