FBSK 3-10/ZFKDS 10 - Plug-in bridge
FBSK 3-10/ZFKDS 10
-
Plug-in bridge
1986657
Fixed bridge, fully insulated, pitch: 10 mm, no. of positions: 3
Product details
Expand all
Collapse all
Technical data
Product properties
Product type
Bridge
Product family
FBSK
Product line
COMBICON Terminals Special
Number of positions
3
Pitch
10 mm
Number of connections
3
Number of rows
1
Number of potentials
3
Dimensions
Pitch
10 mm
Material specifications
Material data - contact
Note
WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201
Contact material
Cu alloy
Material data - housing
Color (Housing)
red (3001)
Insulating material
PA
Insulating material group
I
CTI according to IEC 60112
600
Flammability rating according to UL 94
V0
Glow wire flammability index GWFI according to EN 60695-2-12
850
Glow wire ignition temperature GWIT according to EN 60695-2-13
775
Temperature for the ball pressure test according to EN 60695-10-2
125 °C
Connector
Connection 1
Insulating material
PA
CTI according to IEC 60112
600
Commercial data
Item number
1986657
Packing unit
10 pc
Minimum order quantity
10 pc
Note
Made to order (non-returnable)
Product key
AARZFE
Catalog page
Page 830 (C-1-2013)
GTIN
4017918973117
Weight per piece (including packing)
7.31 g
Weight per piece (excluding packing)
7.162 g
Customs tariff number
85366990
Country of origin
PL
Classifications
ECLASS
ECLASS-13.0
27460406
ETIM
ETIM 9.0
EC002943
UNSPSC
UNSPSC 21.0
39121400
Environmental product compliance
EU RoHS
Fulfills EU RoHS substance requirements
Yes
(No exemptions)
China RoHS
Environment friendly use period (EFUP)
EFUP-E
No hazardous substances above the limits
EU REACH SVHC
REACH candidate substance (CAS No.)
No substance above 0.1 wt%
EF3.0 Climate Change
CO2e kg
0.142 kg CO2e
Compatible products
Expand all
Collapse all
Accessories
ZFKDS 10-10,00
-
PCB terminal block
1986628
ZFKDSA 10-11,7
-
PCB terminal block
1987054
SPTA 16/ 2-10,0-ZB
-
PCB terminal block
1819202
SPTA 16/ 3-10,0-ZB
-
PCB terminal block
1819215
