Power supply unit for AS-Interface systems. Special modules with an output voltage range of 29.5 V - 31.6 V DC are used to supply the AS-Interface systems. The AS-i system also requires a data decoupling network in the power supply unit in order to be able to transmit communication signals along the power line. The ASI QUINT 100-240/2.4 EFD can supply an AS-i system with up to 2.4 A.
Safety through automatic ground fault detection: if two ground faults occur in an AS-i system, this can cause the machines to inadvertently start up or not to be able to stop operation. The ASI QUINT has an integrated ground fault detection function. A ground fault is signaled via LED and via an alarm output.
ASI QUINT 100-240/4.8 EFD
-
Power supply
2736699
Power supply unit für AS interface, 4.8 A, integrated ground fault detector, IP20 degree of protection
Product details
UL Recognized
Approval ID: E211944IECEE CB Scheme
Approval ID: DE/PTZ/0079UL Listed
Approval ID: FILE E 123528cUL Listed
Approval ID: FILE E 123528ASI-Interface
Approval ID: 56301/ 14.06.04
Your advantages
Integrated filters ensure that the modulated data flow is not affected
Integrated ground-fault monitoring signals short circuits on the secondary side
Wide-range input for operation on all common AC and DC networks
