EFG 45-LG/BS GY
-
Electronics housing
2757474
Electronics housing ,Complete housing, length: 118 mm, without vents, Complete housing, cross connection: without bus connector, color: gray, width: 45 mm, height: 137.5 mm, number of positions cross connector: not relevant
Product details
| Product type | Complete housing |
| Housing type | Complete housing |
| Housing series | EFG |
| Product family | EFG..-LG |
| Type | Housing closed, consists of two half shells and a set of three front plates |
| Type | Complete housing |
| Dimensional drawing |
|
| Width | 45 mm |
| Installed height | 137.5 mm |
| Height NS 35/7,5 | 137.5 mm |
| Depth | 118 mm |
| Length | 118 mm |
| Color | gray |
| Flammability rating according to UL 94 | V0 |
| Housing material | PC |
| Ambient conditions | |
| Ambient temperature (operation) | -40 °C ... 125 °C |
