I/O component - ILB PN 24 DI16 DIO16-EF 2702289

Inline, Block IO, PROFINET, RJ45 socket, Digital inputs: 32 (16 fixed and 16 freely selectable), 24 V DC, connection method: 3-wire, Digital outputs: 16, 24 V DC, 500 mA, connection method: 2-wire, PROFINET, -IRT, -MRP, -Fast Startup, degree of protection: IP20, including Inline connector

Show Product Details (PDF)

Product Details



The module is designed for use within a PROFINET network. It is used to acquire and output digital signals.


Order Key 2702289
Packing unit 1 pc
Catalog Page Page 164 (C-6-2019)
GTIN 4055626073323
Weight per Piece (including packing) 563.9 GRM
Weight per Piece (excluding packing) 563.9 GRM
Custom tariff number 85389091
Country of origin DE



UL Recognized

cUL Recognized

PROFINET


Your advantages

16/32 inputs, 24 V DC
16 outputs, 24 V DC, 500 mA
2 RJ45 sockets angled 45°
