The TC MGUARD... security appliances are industrial mobile network routers with mGuard technology. As such, the routers offer a remote maintenance infrastructure for the secure connection of machines and systems via the Internet. A high-speed mobile network interface and a 4-port switch are integrated into a compact metal housing. Secure remote communication on a global scale takes place via 4G LTE as well as UMTS and CDMA networks. With the help of an SD card as a configuration memory, the devices can be quickly and easily started up or replaced. The devices have a buffered realtime clock and Trusted Platform Module (TPM) for secure key generation and management.
TC MGUARD RS4000 4G ATT VPN
-
Router
1010463
Security appliance, version for AT&T (US), WAN and 4G mobile network interface, SD card slot, 10 VPN tunnels, intelligent firewall with full scope of functions, router with NAT/1:1 NAT, optional CIFS Integrity Monitoring, 4 port Managed Switch
Free download available.
Downloads
Product details
cUL Listed
Approval ID: E238705cUL Listed
Approval ID: E366272UL Listed
Approval ID: FILE E 366272cULus Listed
cULus Listed
Your advantages
Integrated 4-port switch
Maximum security with IPsec protocol on Layer 3
Web-based management, SNMP
Replaceable configuration memory
RS-232 interface with COM server function for integrating serial devices
Flexible routing
Up to 10 parallel VPN tunnels (up to 250 possible with additional license as an option)
Supports current certificates such as x509.v3
Stateful inspection firewall for dynamic filtering
Extended temperature rating
