Unslotted sleeves for accommodating cables and lines with a diameter of 2 ... 11 mm, can be used in CES sealing frames
CES-SRC-BK
-
Cable sleeve
0801718
Cable sleeve, small, no. of conductors: 1, type: Round cable, closed, external cable diameter: 1x 2 mm ... 11 mm, material: NBR, color: black, length: 29.5 mm, width: 19.5 mm, height: 17 mm
Product details
| Product type | Cable sleeve |
| No. of conductors | 1 |
| Dimensional drawing |
|
| Width | 19.5 mm |
| Height | 17 mm |
| Length | 29.5 mm |
| Material | NBR |
| External cable diameter | 1x 2 mm ... 11 mm |
| Seal size | small |
| Design, Format | Round cable |
| Design, Cable seal | closed |
| Ambient conditions | |
| Degree of protection | IP54 |
| IP65 (When using cable ties in combination with the installation direction to the side or downwards) | |
| Ambient temperature (operation) | -40 °C ... 125 °C (static) |
| Assembly note | IP54: for vertical sealing frame mounting/for horizontal sealing frame mounting (downward cable outlet direction). IP65: vertical mounting/horizontal mounting (downward cable outlet direction) of the sealing frame directly on the housing panel and use of a 3.6 mm wide cable binder (e.g., item 3240744). |
