FBSK 4-10 - Plug-in bridge
FBSK 4-10
-
Plug-in bridge
1928411
Bridge, fully insulated, pitch 10 mm, 4-pos.
Product details
Expand all
Collapse all
Technical data
Product properties
Product type
Bridge
Product family
FBSK
Product line
COMBICON Terminals Special
Number of positions
4
Pitch
10 mm
Number of connections
4
Number of rows
1
Number of potentials
4
Dimensions
Pitch
10 mm
Material specifications
Material data - contact
Note
WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201
Contact material
Cu alloy
Material data - housing
Color (Housing)
red (3001)
Insulating material
PA
Insulating material group
I
CTI according to IEC 60112
600
Flammability rating according to UL 94
V0
Glow wire flammability index GWFI according to EN 60695-2-12
850
Glow wire ignition temperature GWIT according to EN 60695-2-13
775
Temperature for the ball pressure test according to EN 60695-10-2
125 °C
Connector
Connection 1
Insulating material
PA
CTI according to IEC 60112
600
Commercial data
Item number
1928411
Packing unit
50 pc
Minimum order quantity
50 pc
Sales key
AAR
Product key
AARZFE
Catalog page
Page 830 (C-1-2013)
GTIN
4017918606640
Weight per piece (including packing)
4.378 g
Weight per piece (excluding packing)
4.364 g
Customs tariff number
85366990
Country of origin
PL
Classifications
ECLASS
ECLASS-13.0
27460406
ETIM
ETIM 9.0
EC002943
UNSPSC
UNSPSC 21.0
39121400
Environmental product compliance
EU RoHS
Fulfills EU RoHS substance requirements
Yes
(No exemptions)
China RoHS
Environment friendly use period (EFUP)
EFUP-E
No hazardous substances above the limits
EU REACH SVHC
REACH candidate substance (CAS No.)
No substance above 0.1 wt%
EF3.0 Climate Change
CO2e kg
0.058 kg CO2e
Compatible products
Expand all
Collapse all
Accessories
ZFKDSA 4-10- 4
-
PCB terminal block
1743744
ZFKDSA 4-10- 5
-
PCB terminal block
1990368
ZFKDSA 4-10- 6
-
PCB terminal block
1722561
ZFKDSA 4-10-10
-
PCB terminal block
1735419
ZFKDSA 4-10-12
-
PCB terminal block
1735422
ZFKDS 4-10
-
PCB terminal block
1907539
ZFKDSA 4- 9
-
PCB terminal block
1907542
