Wire marking tag, yellow, cable diameter range: 1.9 ... 3.8 mm, horizontal: Symbols, mounting type: slide-on, text field height: 2.6 mm, text field width: 3.2 mm
Product details
Product type
Labeled conductor marker
Marking
Printing direction
horizontal
Printing
Symbols
Mounting type
slide-on
Color
yellow (RAL 1018)
Material
Ethylene-vinyl acetate (EVA)
Flammability rating according to UL 94
V0
Components
free from silicone, halogen, and cadmium
Ambient conditions
Ambient temperature (operation)
-45 °C ... 70 °C
Ambient temperature (assembly)
> 10 °C
Width
3.2 mm
Length
4.5 mm
External dimensions
Outside diameter
1.9 mm ... 3.8 mm
Text field
Text field width
3.2 mm
Text field height
2.6 mm
Wipe resistance
DIN EN 61010-1 (VDE 0411-1)
General
Please specify the required marking with order: Minimum order per imprint: 1 packing unit
