G-INS-M12-M68N-SNES-S
-
Cable gland
1424541
Cable gland, material for screw connection: Stainless steel 1.4305, application: Standard, external cable diameter 3 mm ... 6.5 mm, shielding: no, connecting thread: M12 x 1.5, color: silver-colored, with O-ring
Product details
| Assembly note | 1) Mount screw connection support in the housing using the correct torque 2) Insert cable 3) Tighten union nut using the correct torque |
| Product type | Cable screw gland |
| Application | Standard |
| No. of conductors | 1 |
| Manufacturer | BIMED |
| Manufacturer Designation | BMSC-0S |
| Shielded | no |
| Execution of the strain relief | A |
| Category of shock impact | 2 |
| Design, Strain relief | A |
| Dimensional drawing |
|
| Length | 33.5 mm |
| Length of the connecting thread | 6 mm |
| Hole diameter | 12.1 mm ... 12.3 mm |
| Wrench size, union nut | 14 mm |
| Wrench size, support | 14 mm |
| Hexagon angular dimension | 15.5 mm |
| Thread type connection side | M12 x 1.5 |
| Thread pitch | 1.5 mm |
| Tightening torque | 5.5 Nm (Cap nut) |
| 3 Nm (Support sleeve) | |
| for UL514 B: union nut |
| Color | Steel/stainless steel color |
| Material Compression ring | PA 6 |
| Seal material O-ring | Perbunan |
| Seal material Cable seal | CR |
| Material for screw connection | Stainless steel 1.4305 |
| External cable diameter Cable 1 | 3 mm ... 6.5 mm |
| External cable diameter | 4 mm ... 6.5 mm (for UL 514 B) |
| Ambient conditions | |
| Degree of protection | IP68 (5 bar, 30 min.) |
| IP66 | |
| IP69 | |
| Ambient temperature (operation) | -40 °C ... 100 °C (static) |
