HC-B-G-M40-EC-AL
-
Cable gland
1411441
EVO EMC cable gland with bayonet locking, B series, size M40, cable diameter: 19 ... 27 mm
Product details
| Product type | Cable screw gland |
| Application | EMC |
| No. of conductors | 1 |
| Type of the screw connection | M40 |
| Shielded | yes |
| Execution of the strain relief | B |
| Dimensional drawing |
|
| Width | 54.2 mm |
| Height | 722.4 mm |
| Depth | 62 mm |
| Wrench size, union nut | 43 mm |
| Thread pitch | 1.5 mm |
| Color | aluminum color |
| Material Pressure screw | Brass, nickel-plated |
| Seal material | NBR |
| Seal material Cable seal | NBR |
| Housing material | Die-cast aluminum, corrosion resistant |
| Material for screw connection | Aluminum |
| External cable diameter Cable 1 | 19 mm ... 27 mm |
| Ambient conditions | |
| Degree of protection | IP66 |
| IP67 | |
| Enclosure rating (NEMA) | 4 (UL 50e) |
| 4X (UL 50e) | |
| 12 (UL 50e) | |
| Ambient temperature (operation) | -40 °C ... 125 °C (static) |
