EtherNet/IP implementation videos

EtherNet/IP implementation videos
Axioline Smart Element configuration with EtherNet/IP integration
Axioline Smart Element configuration with EtherNet/IP integration YouTube

Axioline Smart Element configuration with EtherNet/IP integration

In this video, we will demonstrate how to configure and integrate the EtherNet/IP Axioline digital and analog Smart Elements I/O station into RSLOGIX. Smart Elements was developed with little to no configuration necessary, making the integration process quick and easy.

How to add Smart Elements to an Axioline F I/O station
How to add Smart Elements to an Axioline F I/O station YouTube

How to add Smart Elements to an Axioline F I/O station

This video demonstrates how to add Smart Elements to an Axioline F I/O station. Pluggable Axioline Smart Elements are system-free modules without bus communication. The individual element only supports the I/O function.

How to configure Axioline F Ethernet/IP bus coupler

This video will demonstrate how you can configure an Axioline F Ethernet/IP bus coupler, using Startup+freeware, and then insert it into RS LOGIX 5000.

FL SWITCH 7000 Add-On Instructions (AOI) and HMI faceplates Integration

In this video you will learn how to integrate the FL SWITCH 7000 Add-On Instructions (AOI) and HMI faceplates into RSLogix/Studio5000 and FactoryTalk View projects.

Integrate Axioline and FL Switch 7000 into RS Logix

In this video you’ll learn to how to load AXIOLINE E IP67 I/O and the FL SWITCH 7000 into your Rockwell RS logix 5000 software.

EtherNet/IP Made Easy

Learn to how to use the Ethernet/IP Made Easy tool to configure Phoenix Contact Inline I/O and switches for use in Ethernet/IP networks.
