PLC-RPT-24DC/21HC/EX - Relay Module
2909532

PLC-INTERFACE, consisting of DIN-rail-mountable basic terminal block in 14 mm with Push-in connection and plug-in relay with 10 A power contact, 1 changeover contact, 24 V DC input voltage. Approved according to ATEX/IECEx (Zone 2) and Ex Zone Class I, Div. 2.

Product Details

Utilization restriction
EMC note EMC: class A product, see manufacturer's declaration in the download area
Product type Relay Module
Product family PLC-INTERFACE
Application High continuous currents
potentially explosive areas
Operating mode 100% operating factor
Mechanical service life 3x 107 cycles
Insulation characteristics
Insulation Safe isolation, reinforced insulation
Insulation characteristics: Standards/regulations
Insulation Safe isolation, reinforced insulation
Overvoltage category III
Pollution degree 3
Maximum power dissipation for nominal condition 0.43 W
Test voltage (Winding/contact) 4 kV AC (50 Hz, 1 min., winding/contact)
Standards/regulations
Rated insulation voltage 250 V AC
Rated surge voltage 6 kV
Coil side
Nominal input voltage UN 24 V DC
Input voltage range 20.2 V DC ... 33.6 V DC (20 °C)
Typical input current at UN 18 mA
Typical response time 8 ms
Typical release time 10 ms
Protective circuit Reverse polarity protection; Polarity protection diode
Surge protection; Freewheeling diode
Operating voltage display Yellow LED
Switching
Contact type 1 changeover contact
Type of switch contact Single contact
Drive and function monostable
Drive (polarity) bipolar
Contact material AgNi
Maximum switching voltage 250 V AC/DC (The separating plate PLC-ATP should be installed for voltages larger than 250 V (L1, L2, L3) between identical terminal blocks in adjacent modules. Potential bridging is then carried out with FBST 8-PLC... or ...FBST 500...)
Minimum switching voltage 12 V AC/DC (10 mA)
Limiting continuous current 10 A
6 A (value applies to connections 12. If connections 12 are bridged, the normal value applies.)
Maximum inrush current 30 A (300 ms)
Min. switching current 10 mA (12 V)
Interrupting rating (ohmic load) max. 240 W (at 24 V DC)
58 W (at 48 V DC)
48 W (at 60 V DC)
50 W (at 110 V DC)
80 W (at 220 V DC)
2500 VA (for 250 V AC)
Interrupting rating (ohmic load) max. bridged 144 W (for 24 V DC. Value applies to connections 12. If connections 12 are bridged, the normal value applies.)
1500 VA (for 250 V AC. Value applies to connections 12. If connections 12 are bridged, the normal value applies.)
Switching capacity 2 A (at 24 V, DC13)
0.2 A (at 110 V, DC13)
0.2 A (at 250 V, DC13)
6 A (at 24 V, AC15)
6 A (at 120 V, AC15)
6 A (at 250 V, AC15)
Connection method Push-in connection
Stripping length 10 mm
Conductor cross section solid 0.14 mm² ... 2.5 mm²
Conductor cross section flexible 0.14 mm² ... 2.5 mm²
0.2 mm² ... 2.5 mm² (Single ferrule)
2x 0.5 mm² ... 1 mm² (TWIN ferrule)
Conductor cross section AWG 26 ... 14
Width 14 mm
Height 80 mm
Depth 94 mm
Flammability rating according to UL 94 V0 (Housing)
Ambient conditions
Degree of protection Relay RT III (Relay)
IP20 (Relay base)
Ambient temperature (operation) -20 °C ... 60 °C (UL)
-40 °C ... 60 °C (ATEX / IECEx)
Ambient temperature (storage/transport) -40 °C ... 85 °C
CE
Certificate CE-compliant
ATEX
Identification  II 3G Ex ec nC IIC T4 Gc
Certificate IBExU16ATEXB015 X
IECEx
Identification Ex ec nC IIC T4 Gc
Certificate IECEx IBE 16.0029X
UKCA Ex (UKEX)
Identification  II 3 G Ex ec nC IIC T4 Gc
Certificate PxCIF21UKEX2909514X
UL, USA
Identification Class I, Zone 2, AEx nA nC IIC T6
UL, USA / Canada
Identification Class I, Div. 2, Groups A, B, C, D
UL, Canada
Identification Class I, Zone 2, Ex nA nC IIC Gc T6 X
Corrosive gas test
Identification ISA-S71.04. G3 Harsh Group
EN 60068-2-60
Standards/regulations
Standards/regulations IEC 60664
EN 50178
EN 60079-0, -7, -15
Mounting type DIN rail mounting
Assembly instructions in rows with zero spacing
Mounting position any
Item number 2909532
Packing unit 1 pc
Minimum order quantity 10 pc
Sales Key C05
Product Key CK623A
Catalog Page Page 387 (C-5-2019)
GTIN 4055626363691
Weight per Piece (including packing) 75.05 g
Weight per Piece (excluding packing) 66.03 g
Customs tariff number 85364190
Country of origin DE

ECLASS

ECLASS-9.0 27371601
ECLASS-10.0.1 27371601
ECLASS-11.0 27371601
ECLASS-12.0 27371601
ECLASS-13.0 27371601

ETIM

ETIM 8.0 EC001437

UNSPSC

UNSPSC 21.0 39122300

DNV GL

Approval ID: TAE0000196
Approval Specification Data
Nominal Voltage UN Nominal Current IN Cross Section AWG Cross Section mm2

CCC

Approval ID: 2021122304114118

EAC Ex

Approval ID: RU C-DE.AB72.B.02328

IECEx

Approval ID: IECEx IBE 16.0029X

cUL Listed

Approval ID: FILE E 199827

UL Listed

Approval ID: FILE E 199827

ATEX

Approval ID: IBExU 16 ATEX B015 X

KC-s

Approval ID: 18-KA4BO-0620X

cULus Listed

REACh SVHC Lead 7439-92-1
Hexahydromethylphthalic anhydride
China RoHS Environmentally Friendly Use Period = 50 years
For information on hazardous substances, refer to the manufacturer’s declaration available under “Downloads”
