Wire marking tag, yellow, cable diameter range: 3 ... 6 mm, horizontal: Letters, mounting type: slide-on, text field height: 2.6 mm, text field width: 4.2 mm
Product details
Product type
Labeled conductor marker
Type
Profile
Marking
Printing direction
horizontal
Printing
Letters
Mounting type
slide-on
Color
yellow (RAL 1018)
Material
Ethylene-vinyl acetate (EVA)
Flammability rating according to UL 94
V0
Components
free from silicone, halogen, and cadmium
Ambient conditions
Ambient temperature (operation)
-45 °C ... 70 °C
Ambient temperature (assembly)
> 10 °C
Width
4.2 mm
Height
9.5 mm
Length
6.6 mm
External dimensions
Outside diameter
3 mm ... 6 mm
Text field
Text field width
4.2 mm
Text field height
2.6 mm
Wipe resistance
DIN EN 61010-1 (VDE 0411-1)
General
Please specify the required marking with order: Minimum order per imprint: 1 packing unit
