FLKM 14-PA-MELSEC A1S/O - Front adapter

FLKM 14-PA-MELSEC A1S/O - Front adapter

2289939

VARIOFACE front adapter, for Mitsubishi Electric MELSEC A1S Y80, 2 x 8 channels can be connected

Product details

Expand all Collapse all

Technical data

Product properties

Product type	Front adapter
Insulation characteristics
Insulation	Functional insulation
Overvoltage category	II
Pollution degree	2

Electrical properties

Operating voltage (DC)	≤ 30 V DC
Current (Per path)	≤ 1 A
Current (per connection)	≤ 4 A (Feed-in via separate power supply)
Rated insulation voltage	50 V
Rated surge voltage	0.5 kV

Connection data

Field level
Connection method	IDC/FLK pin strip
Number of connections	2
Number of positions	14
Pitch	2.54 mm

Environmental and real-life conditions

Ambient conditions
Degree of protection	IP00
Ambient temperature (operation)	-20 °C ... 50 °C
Ambient temperature (storage/transport)	-20 °C ... 70 °C

Standards and regulations

Standards/regulations	IEC 60664
Standards/regulations		DIN EN 50178

Mounting

Mounting position	any

Notes

Notes on operation	For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met.

Commercial data

Item number	2289939
Packing unit	1 pc
Note	Made to order (non-returnable)
Sales key	C421
Product key	DK231M
GTIN	4017918057862
Weight per piece (including packing)	101.6 g
Weight per piece (excluding packing)	97.1 g
Customs tariff number	85366990
Country of origin	DE

Classifications

ECLASS

ECLASS-13.0

27242292

Environmental product compliance

China RoHS
Environment friendly use period (EFUP)	EFUP-50 An article-related China RoHS declaration table can be found in the download area for the respective article under "Manufacturer declaration". For all articles with EFUP-E, no China RoHS declaration table issued and required.
EU REACH SVHC
REACH candidate substance (CAS No.)	No substance above 0.1 wt%
