AI-GB 4 - 10 GY
-
Ferrule
2100245
Ferrule, Length contact range: 10 mm, sleeve length: 17 mm, color: gray
Product details
| Product type | Cable end sleeve |
| Conductor category | stranded conductors, class 2, 5, 6 / B, C, K, M |
| Product property | Suitable for AWG/multi-standard cables due to the increased diameter of the insulating collar |
| UL certified | |
| Made from soft tin-plated electrolytic copper | |
| Correspond to the requirements of UL 486F | |
| Plastic collar made of polypropylene | |
| Halogen-free | |
| Long/short-term temperature: +105°C/+120°C |
| Conductor connection | |
| Conductor cross section flexible max. | 4 mm² |
| Conductor cross section AWG max. | 12 |
| Stripping length | 15 mm |
| Dimensional drawing |
|
| Sleeve length | 17 mm |
| Length contact range | 10 mm |
| Maximum stripping length | 15 mm |
| Ferrule diameter | 2.9 mm |
| Sleeve wall thickness | 0.2 mm |
| Insulating collar thickness | 0.3 mm |
| Inner dimensions of the insulating collar | 7.9 mm |
| Color | gray (RAL 7042) |
| Material | CU-DHP |
| Flammability rating according to UL 94 | HB |
| Coating | galvanically tin-plated |
| Surface characteristics | Tin-plated |
| Components | free from silicone and halogen |
| Technical data | |
| Sleeve length | 17 mm |
| Design according to standard | Color code in accordance with DIN 46228-4, UL 486F-E |
Your advantages
Previous methods of achieving correct conductor insulation are much more time consuming
These ferrules can be used for short-circuit-proof cables
