HC-SMR-B10
-
DIN rail mounting frame
1687969
HEAVYCON DIN rail mounting frame, for contact inserts of type B10
Product details
| General | For contact inserts B10, BB18, DD42 and HV3; swiveling frame |
| Product type | DIN rail mounting frame |
| Type | B10 |
| Dimensional drawing |
|
| Width | 55 mm |
| Height | 131.5 mm |
| Length | 156 mm |
| Drill hole distance, horizontal | 70 mm |
| Drill hole distance, vertical | 44 mm |
| Hole diameter | 3 mm |
| Material | PA |
| Flammability rating according to UL 94 | HB |
| Ambient conditions | |
| Ambient temperature (operation) | -20 °C ... 100 °C |
