Battery module, lead AGM, VRLA technology, 24 V DC, 1.2 Ah.
Product details
MINI-BAT – battery module with lead AGM technology for maximum buffer times.
General
Note on the battery
This product contains a battery with a limited shelf life that must be charged every few months. The product packaging indicates when the battery must be started up or recharged. The general shelf life can be found in the energy storage devices area under “Latest startup”.
Input voltage
24 V DC
Buffer period
20 min (2 A)
5 min (5 A)
Nominal output voltage
24 V DC
Output current Imax
15 A
Output fuse
1x 15 A
Connection in parallel
5
Connection in series
no
Battery operation
Nominal output voltage
24 V DC
Nominal output current (IN)
15 A
End-of-charge voltage
27.6 V
Charging current
0.36 A
Nominal capacity
1.2 Ah
Battery module service life
6 Years (20 °C)
Latest startup (battery only) - range
6 Months (0 °C ... 20 °C)
6 Months (20 °C ... 30 °C)
3 Months (30 °C ... 40 °C)
Battery technology
VRLA-AGM
Memory medium
Lead rechargeable battery module
Accumulator type
BB Battery BP1.2-12FR
Number of cells
1
Size designation
Block
Battery pack
yes
IQ technology
no
Suitable for fast charging
yes
Product type
Battery module
Product family
Battery module (device with battery)
Application
for MINI DC-UPS
Disposal
Used batteries must not be thrown away with household waste, they should instead be disposed of in accordance with applicable national regulations.
IQ technology
no
Insulation characteristics
Protection class
III
Width
52 mm
Height
130 mm
Depth
110 mm
Installation dimensions
Installation distance right/left
0 mm / 0 mm
Installation distance top/bottom
50 mm / 50 mm
Housing material
Metal
Type of housing
Steel sheet, zinc-plated
Ambient conditions
Degree of protection
IP20
Ambient temperature (operation)
0 °C ... 40 °C
Ambient temperature (storage/transport)
0 °C ... 40 °C
Max. permissible relative humidity (operation)
95 %
Suited for EX-applications
no
Item number
2866417
Packing unit
1 pc
Minimum order quantity
1 pc
Sales key
CMUEV3
Product key
CMUEV3
Catalog page
Page 353 (C-4-2019)
GTIN
4046356152112
Weight per piece (including packing)
2,210 g
Weight per piece (excluding packing)
1,700 g
Country of origin
CN
ECLASS
ECLASS-13.0
27050403
ETIM
ETIM 9.0
EC003893
UNSPSC
UNSPSC 21.0
26111700
EAC
Approval ID: EAC-Zulassung
EAC
Approval ID: RU S-DE.BL08.W.00764
EAC
Approval ID: RU*DE*01.B.78948/21
EU RoHS
Fulfills EU RoHS substance requirements
Yes
(No exemptions)
China RoHS
Environment friendly use period (EFUP)
EFUP-3
An article-related China RoHS declaration table can be found in the download area for the respective article under "Manufacturer declaration". For all articles with EFUP-E, no China RoHS declaration table issued and required.
