SI-FP-2R1A-U1A
-
Data front plate
1404506
Data front plate with contact inserts, plastic with shielding plate, 2 x RJ45, 8-pos. metal, CAT5e (socket/socket); 1 x USB (socket/socket) type A
Product details
| Assembly note | Strain relief USB internal: cable tie |
| Product type | Data front plate |
| Number of slots | 2 |
| Shielded | yes |
| Rated voltage (III/3) | max. 42.4 V DC (RJ45, USB A, UL-Rating) |
| max. 30 V AC (RJ45, USB A, UL-Rating) | |
| 48 V AC/DC (USB A) | |
| Rated current | max. 175 mA (RJ45, UL rating) |
| 1.5 A (USB A) | |
| Transmission speed | max. 5 Gbps (USB-A 3.0) |
| Tightening torque | 0.8 ... 1 Nm |
| Dimensional drawing |
|
| Width | 50.7 mm |
| Height | 87.5 mm |
| Depth | 60 mm |
| Material Data front plate | PBT (Data front plate) |
| Contact insert design | with 1x RJ45 Socket/socket, snap-in slot locking |
| with 1x USB A 3.0 Socket/socket, snap-in slot locking |
| Ambient conditions | |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -10 °C ... 60 °C |
| Assembly note | suitable for all mounting frames |
