BNB WH:GLEICHE ZAHLEN 14 - Zack marker strip

0810892:0014

Marker pin, labeled with the number: 14, 100 identically printed marker pins per package, white, for terminal block width: 4.2 mm

Product details

Technical data

Product properties

Material specifications

Color	white (RAL 9010)
Material	PA
Flammability rating according to UL 94	V2
Components	free from silicone and halogen

Environmental and real-life conditions

UV resistance
Specification	ISO 4892-2:2013-03 (following)
Wipe resistance of inscriptions
Specification	DIN EN 61010-1 (VDE 0411-1):2011-07
	DIN EN 62208 (VDE 0660-511):2012-06 (in parts)
Ambient conditions
Ambient temperature (operation)	-40 °C ... 100 °C
Recommended ambient temperature (storage/transport)	23 °C
Recommended humidity (storage/transport)	50 %

Dimensions

Standards and regulations

Wipe resistance	DIN EN 61010-1 (VDE 0411-1)

Commercial data

Item number	0810892:0014
Packing unit	100 pc
Minimum order quantity	100 pc
Sales key	BG212B
Product key	BG212B
GTIN	4017918864262
Weight per piece (including packing)	0.045 g
Weight per piece (excluding packing)	0.045 g
Customs tariff number	49119900
Country of origin	PL

Classifications
