VS-15-BU-DSUB-3P-LH - D-SUB contact support

1655328

D-SUB contact carrier, shell size 2, accommodation for 3 combined contacts, type of contact socket, fixing with 4-40 UNC thread and solder pins, for panel mounting frame VS-15-...

Order information:	The contacts must be ordered separately since they are not included in the scope of supply of the combi contact inserts.

Product type	Contact insert
Application	Combination contact insert
Type	D-SUB
Number of positions	3
Connection profile	D-SUB
Number of slots	1
Type	Socket
Shielded	yes

Transmission medium	Copper

Connection method	Wave soldering contacts

Width	21.6 mm
Height	17.1 mm
Length	39.52 mm

Flammability rating according to UL 94	V0
Housing material	Metal
Housing surface material	metal-plated
Contact surface material	Gold
Contact carrier material	PBTP

Mechanical data
Insertion/withdrawal cycles	≥ 500

Ambient conditions
Degree of protection	IP20
Ambient temperature (operation)	-55 °C ... 125 °C

Mounting type	Screw mounting

Item number	1655328
Packing unit	50 pc
Minimum order quantity	50 pc
Sales key	0227*
Product key	ABNCAB
Catalog page	Page 214 (C-2-2013)
GTIN	4046356029261
Weight per piece (including packing)	14.74 g
Weight per piece (excluding packing)	11.45 g
Customs tariff number	85366990
Country of origin	DE

Compatible products

Accessories

Your advantages

Compatible with IP67 sleeve housing and panel-mount frame

Easy assembly

EU RoHS
Fulfills EU RoHS substance requirements	Yes
Exemption	6(a), 6(a)-I
China RoHS
Environment friendly use period (EFUP)	EFUP-50 An article-related China RoHS declaration table can be found in the download area for the respective article under "Manufacturer declaration". For all articles with EFUP-E, no China RoHS declaration table issued and required.
EU REACH SVHC
REACH candidate substance (CAS No.)	Lead (CAS: 7439-92-1)
SCIP	2c77159d-1e74-4443-8e6d-2fa5c0b0380c
