Radioline is the new wireless system for large systems. Special features include extremely easy assignment of inputs and outputs by simply turning the thumbwheel - without any programming. Radioline transmits I/O signals (I/O mode) or serial data (serial mode) and is therefore very versatile. Alternatively, I/O signals can now also be connected to controllers directly using the Modbus protocol (PLC/Modbus RTU mode).
In addition, you can implement various network structures: from a simple point-to-point connection to complex mesh networks. Thanks to the latest Trusted Wireless technology, Radioline is the ideal choice for industrial use.
RAD-900-IFS-AU
-
Wireless module
2702878
Radioline - 900 MHz wireless transceiver with RS-232/485 interface, can be extended with I/O modules, RSMA (female) antenna connection, point-to-point, star, and mesh networks up to 250 stations, range of up to 32 km (line of sight), for use in Australia.
Free download available.
Downloads
Product details
| Trade restriction | |
| CE note | The products are offered exclusively for export outside the EU and the European Economic Area. |
| Product type | Wireless module |
| Operating mode | PLC / Modbus RTU dual mode (Activation and configuration via PSI-CONF software) |
| Insulation characteristics | |
| Overvoltage category | II |
| Degree of pollution | 2 |
| Transient surge protection | yes |
| Supply | |
| Supply voltage | 24 V DC |
| Supply voltage range | 10.8 V DC ... 30.5 V DC |
| Max. current consumption | 328 mA (@24 V DC) |
| Power consumption | 8.4 W (peak; 30 dBm) |
| Digital | |
| Output name | RF link relay output |
| Number of outputs | 1 |
| Contact switching type | Changeover contact |
| Contact material | PdRu, gold-plated |
| Maximum switching voltage | 30 V AC/DC |
| Max. switching current | 500 mA |
| Electrical service life | 5x 105 switching cycles with 0.5 A at 30 V DC |
| Analog | |
| Output name | RSSI voltage output |
| Number of outputs | 1 |
| Voltage output signal | 0 V ... 3 V |
| Connection method | Screw connection |
| Stripping length | 7 mm |
| Conductor cross section, rigid min. | 0.2 mm² |
| Conductor cross section, rigid max. | 2.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 14 |
| Wireless | |
| Range | ≤ 32 km (The range may be considerably above or below that stated, and depends on the environment, antenna technology, and the product used) |
| Serial: RS-232 | |
| Data rate | 300 bps / 600 bps / 1.2 kbps / 2.4 kbps / 4.8 kbps / 9.6 kbps / 19.2 kbps / 38.4 kbps / 57.6 kbps / 93.75 kbps / 115.2 kbps |
| Connection method | COMBICON plug-in screw terminal block |
| D-SUB-9 female connector | |
| Connection technology | 3-conductor |
| Serial: RS-485 | |
| Data rate | 300 bps / 600 bps / 1.2 kbps / 2.4 kbps / 4.8 kbps / 9.6 kbps / 19.2 kbps / 38.4 kbps / 57.6 kbps / 93.75 kbps / 115.2 kbps / 187.5 kbps |
| Connection method | COMBICON plug-in screw terminal block |
| Connection technology | 2-conductor |
| Termination resistor | 390 Ω (switchable via DIP switches) |
| 150 Ω (switchable via DIP switches) | |
| 390 Ω (switchable via DIP switches) | |
| Wireless | |
| Interface description | Trusted Wireless |
| Direction | Bi-directional |
| Frequency | 900 MHz |
| Frequency range | 915 MHz ... 928 MHz |
| Transmission power | max. 1 W (adjustable) |
| Data rate | 16 kbps (adjustable) |
| 125 kbps (adjustable) | |
| 250 kbps (adjustable) | |
| Minimum receiver sensitivity | -112 dBm (16 kbps) |
| -105 dBm (125 kbps) | |
| -102 dBm (250 kbps) | |
| Antenna connection method | RSMA (female) |
| Security | 128-bit data encryption |
| Functions | |
| Wireless licenses | Australia |
| New Zealand | |
| Country support | Australia (RCM) |
| Brazil (ANATEL, ID: 06373-19-06497) | |
| New Zealand (RCM) | |
| Wireless | |
| Frequency band | 900 MHz |
| Wireless standard | Trusted Wireless |
| Status display | LED supply voltage, PWR (green) |
| Green LED (bus communication, DAT) | |
| LED periphery error, ERR (red) | |
| 3x green, 1x yellow LED (LED bar graph receive quality, RSSI) | |
| Green LED (receive data, RX) | |
| Green LED (transmit data, TX) |
| Dimensional drawing |
|
| Width | 35 mm |
| Height | 116 mm |
| Depth | 114.5 mm |
| Color | green |
| Flammability rating according to UL 94 | V0 |
| Housing material | PA 6.6-FR |
| Ambient conditions | |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -40 °C ... 70 °C |
| -40 °F ... 158 °F | |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| -40 °F ... 185 °F | |
| Altitude | 2000 m |
| Permissible humidity (operation) | 20 % ... 85 % |
| Permissible humidity (storage/transport) | 20 % ... 85 % |
| Shock | 16g, 11 ms |
| Vibration (operation) | in accordance with IEC 60068-2-6: 5g, 10 Hz ... 150 Hz |
| Conformity/Approvals | |
| Conformance | RCM |
| Electromagnetic compatibility | Conformance with EMC Directive 2004/108/EC |
| Noise emission | |
| Standards/regulations | EN 55011 Class B |
| Mounting type | DIN rail mounting |
| Assembly note | on standard DIN rail NS 35 in accordance with EN 60715 |
Your advantages
Mesh networks of up to 250 devices
High degree of reliability due to Trusted Wireless 2.0 technology (AES encryption, frequency hopping method, and coexistence management)
Quick and easy startup without programming
Extended temperature range of -40 °C … +70 °C
Range of several kilometers thanks to adjustable data rates for the wireless interface
Integrated RS-232/RS-485 interface
