FLKM 40/S100 - Passive module

FLKM 40/S100 - Passive module

2288752

VARIOFACE output module, 16 channels for Siemens SIMATIC® S5-95U and S5-100U

Product details

Expand all Collapse all

Technical data

Product properties

Product type	Interface module
Product family	VARIOFACE
Number of positions	40
Insulation characteristics
Overvoltage category	II
Pollution degree	2

Electrical properties

Nominal voltage U_N	30 V DC
Max. current carrying capacity per branch	0.5 A (0.1 A output n+1)

Connection data

Field level
Connection in acc. with standard	IEC / EN
Connection method	Screw connection
Stripping length	8 mm
Screw thread	M3
Number of positions	20
Conductor cross section rigid	0.2 mm² ... 4 mm²
Conductor cross section flexible	0.2 mm² ... 2.5 mm²
Conductor cross section AWG	24 ... 12
Controller level
Connection method	IDC/FLK pin strip
Number of connections	1
Number of positions	40
Pitch	2.54 mm

Signaling

Status display	no
Status display present	no

Dimensions

Item dimensions
Width	78.5 mm
Height	90 mm
Depth	68 mm

Material specifications

Color	green (RAL 6021)
Housing insulation material	Polyamide 6.6 green

Environmental and real-life conditions

Ambient conditions
Ambient temperature (operation)	-20 °C ... 50 °C

Standards and regulations

Standards/regulations	IEC 60664
		IEC 60664A
		DIN VDE 0110
		DIN VDE 0160 (in parts)

Mounting

Mounting position	any

Notes

Notes on operation	For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met.

Commercial data

Item number	2288752
Packing unit	1 pc
Minimum order quantity	1 pc
Note	Made to order (non-returnable)
Sales key	0863*
Product key	CK2187
GTIN	4017918057152
Weight per piece (including packing)	155.6 g
Weight per piece (excluding packing)	118.76 g
Customs tariff number	85369010
Country of origin	DE

Environmental product compliance

EU REACH SVHC
REACH candidate substance (CAS No.)	No substance above 0.1 wt%
