RJ45 coupling, degree of protection: IP20, number of positions: 8, 1 Gbps, CAT5 (IEC 11801:2002), material: PA-GF, for VS-08 and push-pull panel mounting frames
Product details
Product type
Female insert
Application
Freenet system
Number of positions
8
Number of slots
2
Type
Socket
Rated voltage (II/2)
72 V DC
Rated current
1.5 A
Frequency range
100 MHz
Housing material
PA-GF
Housing surface material
tin-plated
Contact material
Phosphor bronze
Contact surface material
Gold
Mechanical data
Insertion/withdrawal cycles
>= 100
Ambient conditions
Degree of protection
IP20
Item number
1405617
Packing unit
1 pc
Minimum order quantity
1 pc
Note
Made to order (non-returnable)
Sales key
*****
Product key
ABNABC
Catalog page
Page 728 (C-2-2017)
GTIN
4046356460057
Weight per piece (including packing)
23.2 g
Weight per piece (excluding packing)
22.3 g
Customs tariff number
85366990
Country of origin
DE
China RoHS
Environment friendly use period (EFUP)
EFUP-50
An article-related China RoHS declaration table can be found in the download area for the respective article under "Manufacturer declaration". For all articles with EFUP-E, no China RoHS declaration table issued and required.
