CA-17S1N222S00 - Device connector front mounting

1619933

M23, Device connector front mounting, series: CA, straight, shielded: yes, for standard and SPEEDCON interlock, No. of pos.: 17, Direction of rotation: Standard, contact connection type: Socket, Solder-in connection, Flat gasket, 4x Ø 3.2, flange dimensions: 25 mm x 25 mm, coding: N

Product details

Technical data

Product properties

Product type	Circular connectors (device side)

Dimensions

Length of the solder pin	3.5 mm
	3.5 mm

Connector

Insulating body
Coding	N
Insulation body material	PBT
Contact material	CuZn
Contact surface material	Ni/Au
Connection method	Solder-in connection
Contact switching type	Socket
Application	Signal
Number of positions	17
Direction of rotation	Standard
Connection profile	17
Contact diameter Power contacts	1 mm
Rated current Power contacts	8 A
Rated surge voltage	1.5 kV
Overvoltage category	III
Degree of pollution	3
Housing
Thread type	M23
Type of locking	for standard and SPEEDCON interlock
Pg screw connection	none
Mounting type	Front mounting (4x Ø 3.2 mm)
Flange dimensions	25 mm x 25 mm
Housing material	GD-Zn
Degree of protection (plugged in)	IP67

Environmental and real-life conditions

Ambient conditions
Ambient temperature (operation)	-40 °C ... 125 °C

Commercial data

Item number	1619933
Packing unit	1 pc
Minimum order quantity	1 pc
Note	Made to order (non-returnable)
Sales key	*****
Product key	ABRAEL
Catalog page	Page 330 (C-2-2013)
GTIN	4046356820370
Weight per piece (including packing)	26.9 g
Weight per piece (excluding packing)	23.42 g
Customs tariff number	85366990
Country of origin	DE

Classifications

Approvals

Approval Specification Data
	Nominal voltage U_N	Nominal current I_N	Cross section AWG	Cross section mm²
	48 V	5 A	18

Approval Specification Data
	Nominal voltage U_N	Nominal current I_N	Cross section AWG	Cross section mm²
	48 V	8 A	18

Environmental product compliance

Compatible products

Accessories

Your advantages

Safe use in the field, thanks to high degree of protection

Consistent EMC protection for reliable transmission of signals

Easy device integration: solder-in contacts available in different lengths

EU RoHS
Fulfills EU RoHS substance requirements	Yes
Exemption	6(c)
China RoHS
Environment friendly use period (EFUP)	EFUP-50 An article-related China RoHS declaration table can be found in the download area for the respective article under "Manufacturer declaration". For all articles with EFUP-E, no China RoHS declaration table issued and required.
EU REACH SVHC
REACH candidate substance (CAS No.)	Lead (CAS: 7439-92-1)
SCIP	56a11423-d06a-4d2b-9d5d-091b440f7fe9
