VS-PPC-J-4X-1227 - Power distributor

1405387

Power distributor, degree of protection: IP65, number of positions: 5, material: Metal, connection method: Coupling, cable outlet: straight, color: black, Universal

Product details

Product description

General	This product corresponds to the PROFINET Cabling and Interconnection Technology Guideline for PROFINET regulations, version 2.00, order no: 2.252, Chapter 11 Connectors for 24 Volt Power Supply Cabling and Chapter 13 Application specific Cabling and Interconnection Technology (AIDA)

Product type	Network distributor box
Type	Version 14
Sensor type	Universal
Number of positions	5
Connection profile	Power
Number of slots	4
Cable outlet	straight
Insulation characteristics
Degree of pollution	2

Rated voltage (II/2)	630 V
Rated voltage (III/2)	400 V
Rated voltage (III/3)	24 V
	250 V
Rated surge voltage (II/2)	4 kV
Rated surge voltage (III/2)	4 kV
Rated surge voltage (III/3)	4 kV
Rated current	16 A (at 20 °C)
	16 A
Nominal voltage U_N	24 V
Nominal current I_N	16 A
Transmission medium	Copper

Connection technology
Connection method	Coupling

Width	73 mm
Height	35 mm
Length	58 mm

Color	black
Material	Metal
Flammability rating according to UL 94	V0
Seal material	NBR
Housing material	Metal
Contact surface material	Gold over nickel
Contact carrier material	PA

Mechanical data
Insertion/withdrawal cycles	≥ 100

Ambient conditions
Degree of protection	IP65
Ambient temperature (operation)	-40 °C ... 85 °C
Ambient temperature (storage/transport)	-40 °C ... 85 °C
Ambient temperature (assembly)	-5 °C ... 55 °C

Mounting type	Screw mounting
Assembly note	When mounting the device on a level surface, use the VS-PPC-J-M mounting foot

Commercial data

Item number	1405387
Packing unit	1 pc
Minimum order quantity	1 pc
Sales key	02
Product key	ABNOIA
GTIN	4046356419918
Weight per piece (including packing)	132.1 g
Weight per piece (excluding packing)	132.1 g
Customs tariff number	85444290
Country of origin	DE

Classifications

Approvals

Approval Specification Data
	Nominal voltage U_N	Nominal current I_N	Cross section AWG	Cross section mm²
keine
	24 V	14 A

Approval Specification Data
	Nominal voltage U_N	Nominal current I_N	Cross section AWG	Cross section mm²
keine
	24 V	16 A

Environmental product compliance

Compatible products

Accessories

PHOENIX CONTACT S.A de C.V.

Lago Alberto No. 319 - Piso 9, Colonia Granada, Alcaldía Miguel Hidalgo, México, Ciudad de México, C.P. 11520

Ask a question +52/55/1101-1380 ventas@phoenixcontact.com.mx

ECLASS-13.0	27440390
ECLASS-15.0	27440390

EU RoHS
Fulfills EU RoHS substance requirements	Yes (No exemptions)
China RoHS
Environment friendly use period (EFUP)	EFUP-E No hazardous substances above the limits
EU REACH SVHC
REACH candidate substance (CAS No.)	No substance above 0.1 wt%
