AK 35
-
Connection terminal block
0404046
Connection terminal block, connection method: Screw connection, Rated cross section: 35 mm2, cross section: 2.5 mm2 - 35 mm2, mounting: Neutral busbar, color: silver-colored
Product details
| Product type | Pick-off terminal |
| Number of connections | 1 |
| Number of rows | 1 |
| Maximum power dissipation for nominal condition | 4.06 W |
| Nominal current IN | 125 A |
| Current carrying capacity of the neutral busbar | 140 A |
| Nominal cross section | 35 mm² |
| Level 1 above 1 below 1 | |
| Connection method | Screw connection |
| Screw thread | M6 |
| Tightening torque | 3.2 ... 3.7 Nm |
| Stripping length | 16 mm |
| Connection in acc. with standard | IEC / EN |
| Conductor cross-section rigid | 2.5 mm² ... 35 mm² |
| Cross section AWG | 12 ... 2 (converted acc. to IEC) |
| Conductor cross-section flexible | 2.5 mm² ... 35 mm² |
| Conductor cross-section, flexible [AWG] | 12 ... 2 (converted acc. to IEC) |
| 2 conductors with same cross section, solid | 1.5 mm² ... 16 mm² |
| 2 conductors with same cross section, flexible | 1.5 mm² ... 16 mm² |
| Maximum load current | 125 A (with 35 mm² conductor cross-section) |
| Nominal cross section | 35 mm² |
| Dimensional drawing |
|
| Width | 14.3 mm |
| Height | 26 mm |
| Depth | 43 mm |
| Length | 26 mm |
| Color | silver-colored |
| Flammability rating according to UL 94 | V2 |
| Connection in acc. with standard | IEC / EN |
| Mounting type | Neutral busbar |
