Electronic circuit breaker, reset input and status output, nominal current: 6 A
Product details
Product type
Device circuit breakers
Product family
EC-E
Type
DIN rail module, one-piece
Number of positions
1
Maximum load current
6 A (100 % Duty Cycle, 40 °C)
5 A (100 % Duty Cycle, 50 °C)
Service life electrical
10000
General
Fuse
electronic
Maximum load current
6 A (100 % Duty Cycle, 40 °C)
5 A (100 % Duty Cycle, 50 °C)
Line+ / LOAD+ /0V
Screw thread
M4
Tightening torque
1.5 ... 1.8 Nm
Stripping length
10 mm
Conductor cross section rigid
0.5 mm² ... 10 mm²
Conductor cross section flexible
0.5 mm² ... 10 mm²
2 conductors with same cross section, solid
0.5 mm² ... 4 mm²
2 conductors with same cross section, flexible
0.5 mm² ... 4 mm²
Nominal current
6 A
Nominal voltage
12 V DC
Conductor cross section flexible
0.25 mm² ... 2.5 mm²
Width
12.5 mm
Height
80 mm
Color
black (RAL 9005)
Ambient conditions
Ambient temperature (operation)
-20 °C ... 60 °C (ordinary locations)
Ambient temperature (storage/transport)
-20 °C ... 70 °C
Mounting type
DIN rail: 35 mm
Item number
3000765
Packing unit
10 pc
Minimum order quantity
1 pc
Sales key
CLA
Product key
CLA131
GTIN
4046356708609
Weight per piece (including packing)
71.5 g
Weight per piece (excluding packing)
68 g
Customs tariff number
85362010
Country of origin
DE
ECLASS
ECLASS-13.0
27140401
ETIM
ETIM 9.0
EC003538
UNSPSC
UNSPSC 21.0
39121400
UL Recognized
Approval ID: FILE E 317172
DNV GL
Approval ID: TAE00002HC
cULus Recognized
Approval ID: E123528
cULus Listed
Approval ID: E123528
UL Recognized
Approval ID: FILE E 324415
EU RoHS
Fulfills EU RoHS substance requirements
Yes
Exemption
6(c), 7(a), 7(c)-I
China RoHS
Environment friendly use period (EFUP)
EFUP-25
An article-related China RoHS declaration table can be found in the download area for the respective article under "Manufacturer declaration". For all articles with EFUP-E, no China RoHS declaration table issued and required.
