VS-SI-EB-EMV-2
-
Mounting frame
1656495
Mounting frame, for two front plates or sockets, metal frame, matt nickel-plated, electrically conductive, transparent cover
Product details
| General | With lockable pressure lock |
| Product type | Mounting frame |
| Type | for 2 front plates |
| Dimensional drawing |
|
| Width | 130 mm |
| Height | 35 mm |
| Length | 120 mm |
| Installation dimensions | |
| Width of the assembly cutout | 117 mm |
| Length of the assembly cutout | 91 mm |
| Material Housing | Zinc alloy (nickel-plated) |
| Flammability rating according to UL 94 | V0 |
| Ambient conditions | |
| Degree of protection | IP65 |
| Ambient temperature (operation) | -10 °C ... 60 °C |
| Ambient temperature (storage/transport) | -25 °C ... 70 °C |
| Assembly note | Suitable for panel thicknesses 1 mm ... 5 mm |
