CES-B10-WRG-BK
-
Flat gasket
0801725
Flat gasket made of NBR, size B10
Product details
| Product type | Seal |
| Type | B10 |
| Dimensional drawing |
|
| Width | 57.5 mm |
| Height | 2.5 mm |
| Length | 99.2 mm |
| Drill hole distance, horizontal | 83 mm |
| Drill hole distance, vertical | 32 mm |
| Hole diameter | 4.5 mm |
| Seal material | NBR |
| Ambient conditions | |
| Ambient temperature (operation) | -20 °C ... 80 °C (static) |
