BP 4-5VT - Plug
BP 4-5VT
-
Plug
3208734
Plug for five voltage transducers
Product details
Expand all
Collapse all
Technical data
Product properties
Product type
Plug
Number of positions
10
Pitch
6.1 mm
Number of connections
10
Number of rows
1
Potentials
10
Insulation characteristics
Overvoltage category
III
Degree of pollution
3
Electrical properties
Rated surge voltage
4 kV
Maximum power dissipation for nominal condition
1.02 W
Connection data
Nominal cross section
4 mm²
Rated cross section AWG
10
Screw thread
M4
Tightening torque
1.2 ... 1.5 Nm
Stripping length
8 mm ... 9 mm
Connection in acc. with standard
IEC 61984
Conductor cross section rigid
0.5 mm² ... 2.5 mm²
Cross section AWG
20 ... 14 (converted acc. to IEC)
Conductor cross section flexible
0.5 mm² ... 2.5 mm²
Conductor cross section, flexible [AWG]
20 ... 14 (converted acc. to IEC)
Flexible conductor cross section (ferrule with plastic sleeve)
0.5 mm² ... 2.5 mm²
Nominal current
15 A
Maximum load current
30 A
Nominal voltage
320 V
Dimensions
Width
86.5 mm
Height
56.6 mm
Depth
40 mm
Pitch
6.1 mm
Material specifications
Color
gray (RAL 7042)
Flammability rating according to UL 94
V0
Insulating material group
I
Insulating material
PA
Static insulating material application in cold
-60 °C
Relative insulation material temperature index (Elec., UL 746 B)
130 °C
Fire protection for rail vehicles (DIN EN 45545-2) R22
HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R23
HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R24
HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R26
HL 1 - HL 3
Surface flammability NFPA 130 (ASTM E 162)
passed
Specific optical density of smoke NFPA 130 (ASTM E 662)
passed
Smoke gas toxicity NFPA 130 (SMP 800C)
passed
Mechanical properties
Mechanical data
Open side panel
No
Environmental and real-life conditions
Ambient conditions
Ambient temperature (operation)
-60 °C ... 105 °C (max. short-term operating temperature RTI Elec.)
Ambient temperature (storage/transport)
-25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
Ambient temperature (assembly)
-5 °C ... 70 °C
Ambient temperature (actuation)
-5 °C ... 70 °C
Permissible humidity (storage/transport)
30 % ... 70 %
Standards and regulations
Connection in acc. with standard
IEC 61984
Mounting
Mounting type
Insertion in base strip
Commercial data
Item number
3208734
Packing unit
10 pc
Minimum order quantity
10 pc
Sales key
BE643X
Product key
BE643X
Catalog page
Page 334 (C-1-2019)
GTIN
4055626013008
Weight per piece (including packing)
127 g
Weight per piece (excluding packing)
120 g
Customs tariff number
85366990
Country of origin
PL
Classifications
ECLASS
ECLASS-13.0
27250304
ETIM
ETIM 9.0
EC000897
UNSPSC
UNSPSC 21.0
39121400
Environmental product compliance
EU RoHS
Fulfills EU RoHS substance requirements
Yes
(No exemptions)
China RoHS
Environment friendly use period (EFUP)
EFUP-E
No hazardous substances above the limits
EU REACH SVHC
REACH candidate substance (CAS No.)
No substance above 0.1 wt%
