KDT-ST 14
-
Filler plug
3062032
Filler plug, material: PA, length: 20 mm, diameter: 14 mm
Product details
| General | The filler plugs are used to seal unused cable sleeves. |
| Product type | Sealing plugs |
| Dimensional drawing |
|
| Length | 20 mm |
| Diameter | 14 mm |
| Color | black (RAL 9005) |
| Material | PA |
| Ambient conditions | |
| Degree of protection | IP54 (Observe the assembly instructions) |
| Ambient temperature (operation) | -20 °C ... 80 °C |
| Assembly note | IP54: for vertical sealing frame mounting/for horizontal sealing frame mounting (downward cable outlet direction). |
