DIN rail adapter with RJ45 module for the connection and distribution of Ethernet cables
CUC-PP-D1PGY/R4IDC8
-
DIN rail adapter
1419024
DIN rail adapter, design: RJ45, degree of protection: IP20, number of positions: 8, 10 Gbps, CAT6A, material: PC-GF, connection method: IDC connection, connection cross section: AWG 26- 22, color: gray
Product details
| Product type | Patch panel |
| Housing type | DIN rail adapter |
| Type | Rail-mountable module |
| Number of positions | 8 |
| Connection profile | RJ45 |
| Number of slots | 1 |
| Rated voltage (III/3) | 72 V (DC) |
| Frequency range | 500 MHz |
| Insulation resistance | > 500 MΩ (100 V DC) |
| Nominal voltage UN | 72 V (DC) |
| Nominal current IN | 1.5 A |
| Connection method | IDC connection |
| Dimensional drawing |
|
| Width | 26.8 mm |
| Height | 71 mm |
| Length | 81.4 mm |
| Color | gray |
| Flammability rating according to UL 94 | V0 |
| Housing material | PC-GF |
| Contact material | CuSn |
| Contact surface material | Gold over nickel |
| Contact carrier material | Die-cast zinc alloy |
| Material, protective cover | PC |
| External cable diameter | 4.5 mm ... 9 mm |
| Wire diameter | 0.4 mm ... 0.65 mm |
| Wire diameter including insulation | 0.8 mm ... 1.6 mm |
| Mechanical data | |
| Insertion/withdrawal cycles | ≥ 750 |
| Ambient conditions | |
| Degree of protection | IP20 |
| IP20 | |
| Ambient temperature (operation) | -25 °C ... 70 °C |
| Ambient temperature (storage/transport) | -40 °C ... 70 °C |
| Mounting type | DIN rail mounting |
