PR2-BSC2/4X21 - Relay base - 2833563

Product properties

Product type	Relay socket

Electrical properties

Nominal voltage U_N	300 V AC/DC
Nominal current I_N	12 A

Connection data

Input side
Connection method	Screw connection
Stripping length	7 mm
Screw thread	M3
Conductor cross section rigid	0.2 mm² ... 2.5 mm²
Conductor cross section rigid		0.2 mm² ... 1.5 mm² (2 conductors with the same cross-section)
Conductor cross section flexible	0.2 mm² ... 2.5 mm²
Conductor cross section flexible		0.2 mm² ... 1.5 mm² (2 conductors with the same cross-section)
Conductor cross section AWG	26 ... 14
Conductor cross section AWG		26 ... 16 (2 conductors with the same cross-section)
Output side
Connection method	Screw connection
Stripping length	7 mm
Screw thread	M3
Conductor cross section rigid	0.2 mm² ... 2.5 mm²
Conductor cross section rigid		0.2 mm² ... 1.5 mm² (2 conductors with the same cross-section)
Conductor cross section flexible	0.2 mm² ... 2.5 mm²
Conductor cross section flexible		0.2 mm² ... 1.5 mm² (2 conductors with the same cross-section)
Conductor cross section AWG	26 ... 14
Conductor cross section AWG		26 ... 16 (2 conductors with the same cross-section)

Dimensions

Material specifications

Color	green (RAL 6021)

Environmental and real-life conditions

Ambient conditions
Ambient temperature (operation)	-25 °C ... 85 °C
Ambient temperature (storage/transport)	-25 °C ... 85 °C

Mounting

Mounting type	DIN rail mounting
Mounting position	any

Item number	2833563
Packing unit	10 pc
Minimum order quantity	1 pc
Product key	DK6313
GTIN	4017918933791
Weight per piece (including packing)	70 g
Weight per piece (excluding packing)	62.96 g
Country of origin	CN

China RoHS
Environment friendly use period (EFUP)	EFUP-E No hazardous substances above the limits
EU REACH SVHC
REACH candidate substance (CAS No.)	No substance above 0.1 wt%
