IBS RT 24 DO 32-T
-
I/O module
2752754
INTERBUS-RT digital output module, 32 outputs, 24 V DC, 500 mA, 2-conductor connection technology, IP20 degree of protection, without connector set
Product details
| Supply | |
| I/O voltage | 24 V DC |
| I/O voltage range | 19.2 V DC ... 30 V DC |
| Residual ripple | ± 1.2 VPP |
| Typical current consumption | 100 mA |
| Digital | |
| Number of outputs | 32 |
| INTERBUS remote bus (incoming/outgoing) | |
| Connection method | D-SUB-9 |
| Dimensional drawing |
|
| Width | 125 mm |
| Height | 44 mm |
| Length | 146 mm |
