RCM-A-SCT- 70 - Differential current monitoring

RCM-A-SCT- 70 - Differential current monitoring

2806074

Differential current converter for type A differential current monitor.

This product needs further products for operation. Mandatory accessories

Product details

Expand all Collapse all

Technical data

Product properties

Product type	Current transformer
Insulation characteristics
Overvoltage category	IV
Pollution degree	2

Electrical properties

Typical characteristics
Rated response differential current I_dyn	3 A
Response differential current I_Δn	0.03 A ... 3 A
Rated voltage U_n	690 V
Differential current acquisition characteristic	Type A (50 / 60 Hz)
Rated surge voltage resistance U_imp	8 kV
Rated current I_n	200 A
Max. overcurrent as regards the non-resolution	6 x I_n
Rated differential short-circuit current I_Δc	10 kA
Thermal permanent differential current I_cth	1.5 x I_n
Thermal rated short-time differential current I_th	10 x I_n (for 1 s)
Rated surge differential current I_dyn	25 x I_n

Connection data

Connection method	Screw terminal blocks
Conductor cross section flexible min.	0.2 mm²
Conductor cross section flexible max.	2.5 mm²
Conductor cross section, rigid min.	0.2 mm²
Conductor cross section, rigid max.	4 mm²

Dimensions

Width	33 mm
Height	130 mm
Depth	110 mm

Material specifications

Housing material	PC

Environmental and real-life conditions

Ambient conditions
Degree of protection	IP20 (terminal blocks)
Degree of protection		IP45 (housing)
Ambient temperature (operation)	-20 °C ... 65 °C
Ambient temperature (storage/transport)	-40 °C ... 85 °C

Standards and regulations

Standards/specifications	DIN EN 62020
Standards/specifications	VDE 0663
Standards/specifications	DIN EN 60044-1
Standards/specifications	VDE 0414

Mounting

Mounting type	Screw mounting
Mounting position	any

Commercial data

Item number	2806074
Packing unit	1 pc
Minimum order quantity	1 pc
Product key	CLB213
Catalog page	Page 289 (C-7-2015)
GTIN	4046356504768
Weight per piece (including packing)	323 g
Weight per piece (excluding packing)	323 g
Country of origin	DE

Environmental product compliance

EU REACH SVHC
REACH candidate substance (CAS No.)	No substance above 0.1 wt%

Compatible products

Expand all Collapse all

Mandatory accessories

RCM-A/50/85-264V - Differential current monitoring 2806016
