Wireless receiver, RSMA (female) antenna connection, communication with the ID-S-S 868 sensor via 868 MHz frequency band
The ID-S-RT wireless receiver is part of the Blade Intelligence rotor blade monitoring system for wind turbine generators (WTGs). The Blade Intelligence rotor blade monitoring system allows for recording and detailed analysis of typical measured values for lightning currents, temperature, ice thickness, and bending moments on the rotor of a WTG. It consists of the corresponding sensors, preassembled connecting cables, and a WIL-BI switchgear and controlgear assembly (as the evaluation unit).
| Product type | Wireless element |
| Insulation characteristics | |
| Overvoltage category | III |
| Degree of pollution | 2 |
| Transient surge protection | yes |
| Supply Transmitter | |
| Supply voltage range | 19.2 V DC ... 30.5 V DC |
| Typical current consumption | 41 mA |
| Max. current consumption | 200 mA |
| Connection method | Push-in connection |
| Stripping length | 10 mm |
| Conductor cross section, rigid min. | 0.2 mm² |
| Conductor cross section, rigid max. | 2.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 14 |
| Wireless | |
| Direction | Uni-directional |
| Wireless | |
| Frequency | 868 MHz |
| Antenna connection method | RSMA (female) |
| Functions | |
| Security | 128-bit data encryption |
| Status display | LED supply voltage, PWR (green) |
| LED periphery error, ERR (red) | |
| LED CAN bus, CAN (yellow) | |
| LED HF data, RF (blue) |
| Dimensional drawing |
|
| Width | 17.5 mm |
| Height | 118 mm |
| Depth | 114.5 mm |
| Housing material | PA |
| Ambient conditions | |
| Degree of protection | IP20 |
| IP20 | |
| Ambient temperature (operation) | -40 °C ... 65 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Altitude | to 3000 m |
| Permissible humidity (operation) | 5 % ... 95 % (non-condensing) |
| Shock | 30g, IEC 60068-2-27 |
| Vibration (operation) | 5g, accordance to IEC 60068-2-6 |
| CE | |
| Identification | CE-compliant |
| Note | Directive 2014/53/EU (RED) |
| Electromagnetic HF field | |
| Frequency range | 863 MHz ... 870 MHz (typical: 868 MHz) |
