NW46Z-PCNJ - Female insert

NW46Z-PCNJ - Female insert

1567214

Female insert, nom. voltage: 300 V, nominal current: 10 A, number of positions: 46, mounting type: Panel mount

Product details

Expand all Collapse all

Technical data

Notes

General	For detailed circuit and function configuration, refer to the electrical schematic diagram.

Product properties

Product type	Test socket
Number of positions	46
Insulation characteristics
Overvoltage category	III
Degree of pollution	3

Connection data

Stripping length	12 mm
Connection in acc. with standard	IEC 61984
Nominal current	10 A (when plugged in)
Nominal voltage	300 V (when plugged in)
Cable lug connection
Cross section	1 mm² ... 1.5 mm²
Cross section range AWG	(converted acc. to IEC)

Dimensions

Width	47.6 mm
Height	133.1 mm
Depth	31.5 mm
Plate thickness	2 mm

Material specifications

Color	gray (RAL 7042)
Flammability rating according to UL 94	V0
Insulating material	PA

Environmental and real-life conditions

Ambient conditions
Ambient temperature (operation)	-25 °C ... 70 °C

Standards and regulations

Connection in acc. with standard	IEC 61984

Mounting

Mounting type	Panel mount

Commercial data

Item number	1567214
Packing unit	1 pc
Minimum order quantity	1 pc
Sales key	BE61ZX
Product key	BE61ZX
GTIN	4067923052673
Weight per piece (including packing)	138.3 g
Weight per piece (excluding packing)	126.3 g

Environmental product compliance

EU RoHS
Fulfills EU RoHS substance requirements	Yes (No exemptions)
EU REACH SVHC
REACH candidate substance (CAS No.)	No substance above 0.1 wt%
