HC-BS-PG11
-
Screw plug
1674493
Screw plug, material for screw connection: Brass, nickel-plated, connecting thread: Pg11, color: silver-colored
Product details
| Product type | Plug for cable screw gland |
| Dimensional drawing |
|
| Length | 8 mm |
| Length of the connecting thread | 4.5 mm |
| Diameter | 22 mm |
| 22 mm | |
| Hexagon angular dimension | Diameter (no corners) |
| Thread type connection side | Pg11 |
| Material | Brass, nickel-plated |
| Seal material O-ring | NBR |
| Housing surface material | Ni |
| Material for screw connection | Brass, nickel-plated |
| Halogen-free | no |
| Ambient conditions | |
| Degree of protection | IP68 |
| Ambient temperature (operation) | -20 °C ... 80 °C |
