AE MP SH 480X480 - Mounting panel

0161976

Mounting panel, width: 424 mm, height: 424 mm, color: silver

Product details

Technical data

Product type	Mounting plate

Width	424 mm
Height	424 mm
Drill hole distance, horizontal	410 mm
Drill hole distance, vertical	410 mm
Hole diameter	8.5 mm
Material thickness of mounting panel	2 mm

Color	silver
Material	Steel
Coating	galvanized, yellow passivated

Commercial data

Item number	0161976
Packing unit	1 pc
Minimum order quantity	1 pc
Note	Made to order (non-returnable)
Sales key	BH9
Product key	BH9ZXX
Catalog page	Page 488 (C-5-2015)
GTIN	4055626158228
Weight per piece (including packing)	9.99 g
Weight per piece (excluding packing)	9.99 g
Customs tariff number	94039910
Country of origin	DE

Classifications

Environmental product compliance

PHOENIX CONTACT Middle East FZ LLC

1201N-1206N, Dubai Science Park Towers - North, P.O. Box 345002, Dubai, United Arab Emirates

ECLASS-12.0	27182811
ECLASS-13.0	27182811

EU RoHS
Fulfills EU RoHS substance requirements	Yes (No exemptions)
China RoHS
Environment friendly use period (EFUP)	EFUP-E No hazardous substances above the limits
EU REACH SVHC
REACH candidate substance (CAS No.)	No substance above 0.1 wt%
